Flushing Ring

Flushing Ring

The Ashcroft® flushing ring is providing flushing connection for flush flanged or sandwich type diaphragm seals.
The Ashcroft® FR flushing ring provides a process flushing option for flush flanged diaphragm seals. It can be used to flush, sample, or vent process when used with isolating valves.

Key Features

Selection of wetted materials

Provides a process flushing option for flush flanged diaphragm seals

NACE compliant (optional)

Can be used to flush, sample, or vent process when used with isolating valves

Material certificates to EN 10204:2004 3.1

Markets & Applications

Chemical and Petrochemical

Energy

Oil and Gas

Pulp and Paper

Machine Automation

Hydrogen and Technical Gases

Pumps and Compressors

  • Specifications
  • Downloads

Process Connection Size

1" ... 4"

DN25 ... DN100

Process Connection Style

Flange according to ASME B16.5

Flange according to EN 1092-1

Pressure Rating

PN10 ... PN400

150 ... 2500 lbs.

Wetted Parts Material

Stainless steel 316L (1.4404)

Monel

Hastelloy C

Duplex

Inconel

Stainless steel 904L (1.4539)

Hastelloy B
